30W 60W 80W 96W 100W 120W 150W 180W 192W 200W 288W 300W 500W 600W CV 0-10V Dimmable LED Power Supplies 12 24 36 48 Volt

Kapangyarihan ng Ouput:
Class 2 30W
Class 2 60W
Class 2 80W
Klase 2 96W
100W
120W
150W
200W
300W
500W
600W
Class 2 180W
Class 2 192W
Class 2 288W
Class 2 300W
Availability:
Magtanong Idagdag sa Basket

  • KVE-DMWA

  • 0-10V

  • Nakahiwalay

  • Patuloy na Boltahe

  • Pagdidilim

  • IP66, Tuyo at Mamasa, Basa

  • 110-277VAC

  • 30W, 60W, 80W, 96W, 100W, 120W, 150W, 200W, 300W, 500W, 600W, 180W, 192W, 288W

  • 12/ 24/ 36/ 48V

  • UL & cUL, FCC, Class 2, ICES

Advantage

30W 60W 80W 96W 100W 120W 150W 180W 192W 200W 288W 300W 500W 600W CV 0-10V Dimmable LED Power Supplies 12 24 36 48 Volt


US Patents No. 9,942,959; Blg. 10,039,167; No. 9,661,710; No. 9,961,724


Output:

Patuloy na Boltahe

Saklaw:

100-277VAC

Disenyo ng PFC:

Built-in na aktibong PFC function

Mga Proteksyon:

Short circuit/ over load/ over temperature

Pagwawaldas ng init:

Paglamig sa pamamagitan ng libreng air convection

Hindi tinatagusan ng tubig na pagganap:

Para sa tuyo, mamasa at basa na lokasyon

Dimming function:

Dimming range:

0-10V dimming: 0-10V/1-10V/Potentiometer/10V PWM 4 in 1

0-100%

Application:

Angkop para sa LED lighting at moving sign na mga application

Warranty:

5 taon na warranty


Pagtutukoy


Lakas ng Output

Numero ng Modelo

Output Voltage

Kasalukuyang Output

Boltahe ng Input

Sukat

Timbang

30W

KVE-12030-DMWA

12V

5A

100-277V AC

167*61.4*25.5mm

kg

KVE-24030-DMWA

24V

2.5A

KVE-33030-DMWA

36V

1.67

KVE-48030-DMWA

48V

1.25A

60W

KVE-12060-DMWA

12V

5A

188*95.4*42.7mm

KVE-24060-DMWA

24V

2.5A

KVE-36060-DMWA

36V

1.67

KVE-48060-DMWA

48V

1.25A

80W

KVE-12080-DMWA

12V

6.66A

KVE-24080-DMWA

24V

3.34A

KVE-36080-DMWA

36V

2.22A

KVE-48080-DMWA

48V

1.67A

96W

KVE-24096-DMWA

24V

4A

KVE-36096-DMWA

36V

2.67A

KVE-48096-DMWA

48V

2A

100W

KVE-12100-DMWA

12V

8.34A

KVE-24100-DMWA

24V

4.17A

KVE-36100-DMWA

36V

2.78A

KVE-48100-DMWA

48V

2.09A

120W

KVE-12120-DMWA

12V

10A

KVE-24120-DMWA

24V

5A

KVE-36120-DMWA

36V

3.33A

KVE-48120-DMWA

48V

2.5A







Lakas ng Output

Numero ng Modelo

Output Voltage

Kasalukuyang Output

Boltahe ng Input

Sukat

Timbang

150W

KVE-12150-DMWA

12V

12.5A

100-277V AC

200*78*25mm

kg

KVE-24150-DMWA

24V

6.25A

KVE-36150-DMWA

36V

4.17A

KVE-48150-DMWA

48V

3.13A

200W

KVE-12200-DMWA

12V

16.67A

KVE-24200-DMWA

24V

8.34A

KVE-36200-DMWA

36V

5.56A

KVE-48200-DMWA

48V

4.17A







Lakas ng Output

Numero ng Modelo

Output Voltage

Kasalukuyang Output

Boltahe ng Input

Sukat

Timbang

300W

KVE-12300-DMWA

12V

25A

100-277V AC

232*78*25mm

1.65kg

KVE-24300-DMWA

24V

12.5A

KVE-36300-DMWA

36V

8.33A

KVE-48300-DMWA

48V

6.25A







Lakas ng Output

Numero ng Modelo

Output Voltage

Kasalukuyang Output

Boltahe ng Input

Sukat

Timbang

500W

KVE-12150-DMWA

12V

12.5A

100-277V AC

284*109*48.5mm

kg

KVE-24150-DMWA

24V

6.25A

KVE-36150-DMWA

36V

4.17A

KVE-48150-DMWA

48V

3.13A

600W

KVE-12200-DMWA

12V

16.67A

KVE-24200-DMWA

24V

8.34A

KVE-36200-DMWA

36V

5.56A

KVE-48200-DMWA

48V

4.17A







Lakas ng Output

Numero ng Modelo

Output Voltage

Kasalukuyang Output

Boltahe ng Input

Sukat

Timbang

180W
(60W * 3)

KVE-C12180-DMWA

12V

5A * 3

100-277V AC

232*78*25mm

300W
(60W * 5)

KVE-C12300-DMWA

12V

5A * 5

279*78*25mm

192W
(96W * 2)

KVE-C24192-DMWA

24V

4A * 2

100-277V AC

232*78*25mm

KVE-C36192-DMWA

36V

2.67A * 2

KVE-C48192-DMWA

48V

2A * 2

288W
(96W * 3)

KVE-C24288-DMWA

24V

4A * 3

279*78*25mm

KVE-C36288-DMWA

36V

2.67A * 3

KVE-C48288-DMWA

48V

2A * 3



0-10V LED Power Supply Wiring Diagram

0-10V LED Power Supply

1-10V Potentiometer Connecting Diagram

10V PWM Connecting Diagram

0-10V Connecting Diagram



0-10V LED Power Supply  Sukat:


download spec_30W 0-10V dim. Driver ng CV KVE-DMWA-BH 12V&24V&48V.pdf

download spec_60W 0-10V dim. Driver ng CV KVE-DMWA-BH 12V&24V&48V.pdf

download spec_80W 0-10V dim. CV driver KVE-DMWA-BH 24V&48V.pdf

download spec_96W 0-10V dim. CV driver KVE-DMWA-BH 24V&48V.pdf

download spec_100W 0-10V dim. Driver ng CV KVE-DMWA-BH 12V&24V&48V.pdf

download spec_120W 0-10V dim. Driver ng CV KVE-DMWA-BH 12V&24V&48V.pdf

download spec_150W 0-10V dim. CV driver KVE-DMWA-BH 12V&24V&36V&48V.pdf

download spec_192W 0-10V dim. CV driver KVE-DMWA-VH 24V&48V.pdf

download spec_200W 0-10V dim. Driver ng CV KVE-DMWA-BH 12V&24V&48V.pdf

download spec_300W 0-10V dim. CV driver KVE-DMWA-BH 12V&24V&36V&48V.pdf

download spec_500W 0-10V dim. CV driver KVE-DMWA-BH 12V&24V&36V&48V.pdf

download spec_600W 0-10V dim. Driver ng CV KVE-DMWA-BH 24V&36V&48V.pdf
