60 Watt CV RGB CW 1 - 5 Channels Dimmable Tuya Lifesmart LED Driver Home Lighting for Zigbee LED Light Strip bar

60 Watt CV RGB CW 1 - 5 Channels Dimmable Tuya Lifesmart LED Driver Home Lighting for Zigbee LED Light Strip bar

Availability:



Inquire Add to Basket

Dimming Type:
ZigBee (Tuya, Smart Life)
Isolated Type:
Isolated
Output Type:
Constant Voltage
Output Channels:
Dimming, CCT, RGBCW, Warm-dim
IP Rate:
IP66, Dry & Damp, Wet
Input Voltage:
100-277VAC
Output Power:
60W
Output Voltage:
12/ 24/ 36/ 48V
Certification:
UL & cUL, CE, RoHS, REACH

Advantage

60 Watt CV RGB CW 1 - 5 Channels Dimmable Tuya Lifesmart LED Driver Home Lighting for Zigbee LED Light Strip bar

Specification

Output Power	Model Number	Output Voltage	Output Current	Output Power	Size
1 Channel	KVZ-12060-1C-JV2	12V	5A	60W	J10: 3507726mm J12-5: 3507737mm
	KVZ-24060-1C-JV2	24V	2.5A
	KVZ-36060-1C-JV2	36V	1.67
	KVZ-48060-1C-JV2	48V	1.25A
2 Channel	KVZ-12060-2C-JV2	12V	5A
	KVZ-24060-2C-JV2	24V	2.5A
	KVZ-36060-2C-JV2	36V	1.67
	KVZ-48060-2C-JV2	48V	1.25A
3 Channel	KVZ-12060-3C-JV2	12V	5A
	KVZ-24060-3C-JV2	24V	2.5A
	KVZ-36060-3C-JV2	36V	1.67
	KVZ-48060-3C-JV2	48V	1.25A
4 Channel	KVZ-12060-4C-JV2	12V	5A
	KVZ-24060-4C-JV2	24V	2.5A
	KVZ-36060-4C-JV2	36V	1.67
	KVZ-48060-4C-JV2	48V	1.25A
5 Channel	KVZ-12060-5C-JV2	12V	5A
	KVZ-24060-5C-JV2	24V	2.5A
	KVZ-36060-5C-JV2	36V	1.67
	KVZ-48060-5C-JV2	48V	1.25A
