30 60 80 100 Watt CV Triac Dimmable LED Power Supplies for LED Strip Lights
Output: | Constant Voltage |
Range: | 200-240VAC |
PFC design: | Built-in active PFC function,PF≥0.95 |
Efficiency: | Up to 85% |
Protections: | Short circuit/over temperature/over load |
Heat dissipation: | Cooling by free air convection |
Waterproof performance: | IP20 (EU) |
Dimming function: | PWM & Voltage reduce (VR) mode can be switched Phase dimming: work with Forward phase, MLV and Reverse phase, ELV, TRIAC dimmers. |
Dimming range: | 0-100% |
Application: | Suitable for LED lighting and moving sign applications |
Warranty: | 5 years warranty |
Others | High efficiency, smaller size, high power factor, low THD |
Output Power | Model Number | Output Voltage | Output Current | Size | Weight |
30W | KVE-12030-TDH | 12V | 2.5A | 155*24*20mm | 0.21kg |
KVE-24030-TDH | 24V | 1.25A |
KVE-36030-TDH | 36V | 0.83A |
KVE-48030-TDH | 48V | 0.63A |
60W | KVE-12060-TDH | 12V | 5A | 178*61*24mm | 0.35kg |
KVE-24060-TDH | 24V | 2.5A |
KVE-36060-TDH | 36V | 1.67 |
KVE-48060-TDH | 48V | 1.25A |
80W | KVE-12080-TDH | 12V | 6.66A |
KVE-24080-TDH | 24V | 3.34A |
KVE-36080-TDH | 36V | 2.22A |
KVE-48080-TDH | 48V | 1.67A |
96W | KVE-24096-TDH | 24V | 4A |
KVE-36096-TDH | 36V | 2.67A |
KVE-48096-TDH | 48V | 2A |
100W | KVE-12100-TDH | 12V | 8.34A |
KVE-24100-TDH | 24V | 4.17A |
KVE-36100-TDH | 36V | 2.78A |
KVE-48100-TDH | 48V | 2.09A |
Triac LED Driver Wiring Diagram
Triac LED Driver Wiring Diagram
Product Overview
The 30 60 80 100 Watt CV Triac Dimmable LED Power Supplies for LED Strip Lights is a versatile and reliable solution designed to power LED strip lights in indoor environments. With four selectable output voltage options—12V, 24V, 36V, and 48V—it offers flexibility to match the requirements of various LED strip configurations. This power supply integrates Triac dimming technology, enabling smooth and flicker-free brightness adjustment from 0-100%, making it ideal for creating dynamic lighting effects in commercial spaces, and architectural installations.
Product Features
Triac Dimming Capability
The power supply supports Triac dimming, compatible with standard Triac dimmers commonly used in residential and commercial lighting systems. This technology allows for seamless and precise control over LED strip brightness, eliminating flickering and ensuring consistent lighting quality. Whether adjusting ambiance for a patio or highlighting architectural details, the dimming function delivers reliable performance.
Multiple Voltage Options
Choose from four output voltage models—KVE-12100-TDH (12V/8.34A), KVE-24100-TDH (24V/4.17A), KVE-36100-TDH (36V/2.78A), and KVE-48100-TDH (48V/2.09A)—to match the voltage requirements of your LED strips. This flexibility simplifies system design and ensures optimal power delivery, reducing energy waste and maximizing efficiency.
High Power Output
Delivering a continuous 100W power output, this supply ensures stable performance for demanding indoor lighting setups. it features silent operation, overload protection and compact design.
Compact and Lightweight Design
Despite its high power capacity, the power supply is designed to be compact and easy to install. Dimensions vary by power output model (e.g., 155×24×20mm for 30W models), and weight ranges from 0.21kg for lower wattage options, ensuring flexibility in mounting locations. Specific size and weight details for 100W models are available in the product specifications.
Wide Input Voltage Range
The power supply accepts input voltages from 200-240V AC, making it suitable for EU applications.
Rugged Outdoor Performance
Built with a waterproof enclosure, the power supply is designed to withstand rain, dust, and temperature fluctuations. While the exact IP rating is not specified, its robust construction ensures reliable operation in outdoor environments, making it suitable for year-round use.
Safety and Protection
The power supply includes built-in safeguards against overvoltage, overcurrent, and short circuits, protecting both the power supply and connected LED strips from damage. This ensures safe operation and extends the lifespan of the lighting system.
Applications
Commercial Lighting: Suitable for outdoor signage, storefronts, and parking areas, ensuring visibility and safety.
Event Lighting: Create immersive lighting setups for weddings, festivals, and temporary installations.
FAQ
Q: What LED strip types are compatible with this power supply?
A: This 100W Indoor Triac Dimmable LED Power Supply for Strips is compatible with Triac-dimmable LED strips operating at 12V, 24V, 36V, or 48V. Ensure the strip’s power requirements match the selected voltage model.
Q: Can I use this power supply with non-Triac dimmers?
A: While the power supply is optimized for Triac dimmers, compatibility with other dimmer types (e.g., 0-10V, PWM) may vary. For non-Triac systems, consider alternative dimming solutions.
Q: Is the power supply suitable for extreme weather conditions?
A: No, this power supply is designed specifically for indoor commercial lighting applications (retail, offices, hospitality).
Q: How do I choose the right voltage model?
A: Select the voltage model that matches your LED strip’s operating voltage. For example, use KVE-12100-TDH for 12V strips, KVE-24100-TDH for 24V strips, KVE-36100-TDH for 36V strips and KVE-48100-TDH for 48V strips. Refer to the strip’s specifications for voltage and current requirements.
Discover our 30 60 80 100 Watt Triac Dimmable LED Power Supply for LED strips, engineered for commercial lighting projects. As a manufacturer, we provide custom solutions, bulk supply options, and robust technical support to meet commercial lighting demands. Enhance reliability and dimming performance for contractors and suppliers with our energy-efficient, IP-rated drivers.
