Model Number | Output Power | Output Voltage | Output Current | Channels |
SDD-12060-CCT | 60W
Class2 | 12V | 5A | 2CH (Dimming & tunable color temperature) |
SDD-24060-CCT | 24V | 2.5A |
SDD-48060-CCT | 48V | 1.25A |
SDD-24096-CCT | 96W
Class2 | 24V | 4A |
SDD-48096-CCT | 48V | 2A |
SDD-12120-CCT | 120W 2*60W | 12V | 10A |
SDD-24160-CCT | 160W 2*80W | 24V | 6.67A |
SDD-48160-CCT | 48V | 3.33A |
Output: | Constant Voltage |
Input Range: | 120VAC |
PFC design: | Built-in active PFC function |
Protections: | Short circuit/ Over load/ Over temperature |
Heat dissipation: | Cooling by free air convection |
Waterproof performance: | For dry and damp locations (US) |
Design features: | 1) Fine-tune Voltage slightly 2) Preset dimmer with on/off function 3) 3-Way switches 4) Dimming and color temperature adjustment function 5) Eliminated compatibility issues between drivers and switches |
Dimming range: | 0.3%-100% |
Application: | Suitable for the application of LED lighting |
Warranty: | 5 years warranty |
Others: | 16KHZ PWM output with dimming curve is a gamma 2.2 curve Flicker-free |
duct Mode |  | SDD-CCT |  | SDD-DIM |  | SDD-ND |
Built in LED Driver | CCT LED Driver+Dimmer 2 in 1 | Dimming LED Driver+Dimmer 2 in 1 | On/Off LED Driver |
CCT Dimmer | √ | × | × |
Brightness | √ | √ | × |
ON/OFF Switch | √ | √ | √ |
Input Voltage | 120V 60Hz | 120V 60Hz | 120V 60Hz |
Output Voltage | 12/24/48V | 12/24/48V | 12/24/48V |
Output Power | 60/96/120/160W | 60/96/120/160W | 60/96/120/160W |
3-Way/single Pole | 3-Way / Single Pole | 3-Way / Single Pole | 3-Way / Single Pole |
Certificated | UL/cUL Listed | UL/cUL Listed | UL/cUL Listed |
Crucial Note: To guarantee performance and safety, please verify your circuit is a standard configuration. Do not use the SDD series in special circuits.
60W 96W 120W 160W CV 2CH Dimming CCT Driver + Dimmer 2 in 1 of Wired SwitchingLed Lighting
All-in-One LED Driver + Dimmer– This 2-in-1 device integrates a built-in LED driver and tunable dimming controls.Simple, flexible, and ready to use.
The Dimming CCT Driver + Dimmer 2-in-1 : Illuminate Your Comfortable Life
Simplify Installation. Enjoy Whole-Home Smart Lighting with 99% Seamless Compatibility.
With this smart driver + dimmer 2-in-1, you can easily create the perfect ambiance for any smart home scene, using light to set the mood and function of every space.
3-way circuit
Ideal for creating personalized ambient light control in bedrooms, living rooms, hallways with three-way switches, and more.
Why Our Global Manufacturing Benefits You:
Assured Quality for Your Lighting System: Our commitment to international quality control, upheld in both Vietnam and China, ensures that every driver+dimmer 2 in 1 unit delivers the durable, high-performance reliability you expect from a premium dimmable LED driver.
Rigorous Testing for Guaranteed Performance: Every dimmable LED driver we produce—whether manufactured in Vietnam or China—is subjected to identical rigorous testing protocols, guaranteeing that each driver+dimmer 2 in 1 delivers smooth, flicker-free dimming and long-term operational stability.
