Products Detail

You are here: Home / Products / Canada 200-347VAC LED Driver / DALI-2 D4i / 192W 200W CCT DALI 2 D4i Dimmable Constant Voltage L E D Driver 4A 8A

loading

192W 200W CCT DALI 2 D4i Dimmable Constant Voltage L E D Driver 4A 8A

Ouput Power:
192W Class 2
200W
Availability:
Inquire Add to Basket

  • DMX512

  • Isolated

  • Constant Voltage

  • Dimming, CCT

  • IP66, Dry & Damp, Wet

  • 100-277VAC

  • 200W, 192W

  • 12/ 24/ 36/ 48V

  • UL & cUL, FCC, Class 2, ICES, RoHS, REACH

Advantage

192W 200W CCT DALI 2 D4i Dimmable Constant Voltage L E D Driver 4A 8A

Flicker-free,

output dimming frequency 20KHz reach the exemption level,

Digital dimming,

single light control,

with auxiliary power supply & temperature control


Specification of 192W 200W CCT DALI L E D Driver


Model Number

Watts

Output Voltage

Output Current

Class 2

Listings

Power Factor (Typ.)

Output Mode

Size

Weight

KVC-12060-D4IJ-YT

60W

12V

5A

Yes

cUL, UL, FCC, ICES, CE, RoHS, Reach

PF≥0.95

Dimming

202.5*114.2*40mm


KVC-24060-D4IJ-YT

24V

2.5A

KVC-36060-D4IJ-YT

36V

1.67

KVC-48060-D4IJ-YT

48V

1.25A


KVC-24096-D4IJ-YT

96W

24V

4A

Yes

cUL, UL, FCC, ICES, CE, RoHS, Reach

PF≥0.93

Dimming

241*125*40mm


KVC-36096-D4IJ-YT

36V

2.67A

KVC-48096-D4IJ-YT

48V

2A

KVC-12100-D4IJ-YT

100W

12V

8.34A

No

KVC-24100-D4IJ-YT

24V

4.17A

KVC-36100-D4IJ-YT

36V

2.78A

KVC-48100-D4IJ-YT

48V

2.09A

KVC-12120-D4IJ-YT

120W

12V

10A

No

KVC-24120-D4IJ-YT

24V

5A

KVC-36120-D4IJ-YT

36V

3.33A

KVC-48120-D4IJ-YT

48V

2.5A


KVC-C24192-2G-D4IJ-YT

192W

24V

2*4A

Yes

cUL, UL, FCC, ICES, CE, RoHS, Reach

PF≥0.95

CCT
Dimming

293*125*42.7mm


KVC-C36192-2G-D4IJ-YT

36V

2*2.67A

KVC-C48192-2G-D4IJ-YT

48V

2*2A

KVC-12200-2G-D4IJ-YT

200W

12V

16.67A

No

KVC-24200-2G-D4IJ-YT

24V

8.33A

KVC-36200-2G-D4IJ-YT

36V

5.56A

KVC-48200-2G-D4IJ-YT

48V

4.16A



DALI LED Driver Wiring Diagram
